This innovative Telescoping Flagpole offers every home or business owner the opportunity to easily and conveniently add beauty and charm to their landscape designs. With the pole in the lowered position, attach the flag to the harness assemblies and raise each section, locking them in place with a spring release button. Simply press the release button to lower the pole.

Each pole assembly comes complete with a ground sleeve, all necessary hardware,swivel hooks for up to two flags , and a gold anodized aluminum 3" top ball.

The innovative flag attachments allow the flag to revolve around the pole-no tangles or knots to deal with. The 20' model is equipped to fly two flags simultaneously, or to fly with one flag at half mast.

• Removes for easy storage
• Constructed of sturdy 16-gauge aluminum
• New innovative attachment allows flag to revolve around the pole
• No twisted or tangled flags
• No clanging ropes, sticking pulleys or old-fashioned tie-downs
• Available in popular 20 foot above-ground heights
• For residential or light commercial applications
• 2 year warranty


  The 20' Telescoping Flagpole is only $229.00
  FREE SHIPPING WITHIN CONTINENTAL UNITED STATES



  Ground Sleeve Installation a.k.a. Ground Mount, Foundation Mount or Groundset, For Continental and Sentry flagpoles. DOES NOT apply to Telescoping and Estate flagpoles.

  Ground mounted installations Ground Mount The embedded, or Groundset, mount is the method of choice for mounting aluminum flagpoles at grade. Flagpole shafts so mounted have a higher wind speed rating than the same shafts base-plate mounted. Specifications: 2.3 A FOUNDATION TUBE: Fabricated from 16 ga. galvanized steel, with a steel base plate whose square dimension is at least the internal diameter of the sleeve plus 4''. A setting plate 6'' square shall be securely welded to the ground spike at least 6'' below the base plate. The ground spike shall be 3/4'' diameter, not less than 18'' long. 1. Provide spun aluminum collar, Type FC-11, finished to match flagpole shaft. Diameter shall be at least 1'' greater than diameter of sleeve.




  Ground Sleeve Specifications
  Shaft Foundation Dimensions
  HEIGHT	BUTT DIAMETER	SLEEVE DIAMETER	DEPTH A	DEPTH B	DEPTH C
  20'	4"	6"	3' 6"	30"	24"
  20'	5"	8"	3' 6"	30"	24"
  25'	5"	8"	3' 6"	30"	24"
  25'	5.5" - 6"	10"	3' 6"	30"	24"
  30'	5"	8"	3' 6"	30"	24"
  30'	6"	10"	3' 6"	30"	24"
  35'	5"	8"	4' 0"	36"	30"
  35'	6" - 7"	10"	4' 0"	36"	30"
  40'	7"	10"	4' 6"	42"	36"
  40'	8"	12"	4' 6"	42"	36"
  45'	8"	12"	5' 0"	48"	42"
  50'	8"	12"	5' 6"	48"	42"
  50'	10"	15"	5' 6"	48"	42"
  60'	10" - 12"	15"	6' 10"	48"	42"
  70'	10" - 12"	15"	8' 0"	60"	48"
  80'	12"	15"	9' 0"	60"	48"
